2800 watt/120 volt AC Inverter with 125 amp PFC Charger | Magnum Energy MS2812-L
Special Price
$2,388.39
Regular Price
$3,070.46
SKU
Brand: Magnum Energy
MAG-MS2812-L
- Input battery voltage range: 9 - 16.8 VDC
- AC output voltage accuracy: 120 VAC ± 5%
- Output frequency and accuracy: 60 Hz ± 0.1 Hz
- Total Harmonic Distortion (THD): < 5%
- 1 msec surge current (amps AC): 70
- 100 msec surge current (amps AC): 40
- 5 sec surge power (real watts): 3900
- 30 sec surge power (real watts): 3800
- 5 min surge power (real watts): 3200
- 30 min surge power (real watts): 3000
- Output power (continuous watts): 2800
- Maximum continuous input current: 373 ADC
- Inverter efficiency (peak): 90%
- AC Relay Transfer time (minimum): 16 msecs
- Power Consumption - searching: < 8 watts
- Power Consumption - inverting (no load): 30 watts
- Output Waveform: Pure Sine Wave
- Continuous charger output at 25° C: 125 ADC
- Charger efficiency: 85%
- Power factor: > .95
- Input current for continuous rated output: 18 AAC
- Transfer relay capability: 60ACC total
- Five stage charging capability: Bulk, Absorb, Float, Equalize (requires remote), and Battery Saver
- Battery temperature compensation: Standard with available temp sensor connected (battery temp 0-50° C)
- Internal cooling: 0 to 120 cfm variable speed drive using dual 92mm brushless DC fans
- Overcurrent protection: Yes, with two overlapping circuits
- Overtemperature protection: Yes on transformer, MOSFETS, and battery
- Corrosion protection: Yes, PCB’s conformal coated, powder coated chassis/top, and stainless steel fasteners
- Warranty: Three years parts and labor
- Physical dimensions (l x w x h): 13.75 x 12.65 x 8.0 inches (34.9 cm x 32.1 cm x 20.3 cm)
- Mounting: Shelf or wall (vents not allowed to face downward unless ME-CB or MMP/MP is installed)
- Unit weight: 55 pounds (24.9 kg)
- Shipping weight: 62 pounds (28.1 kg)
- Max operating altitude: 15,000 feet (4570 m)
- Temperature (Operating/Non-operating): -20° C to +60° C (-4° F to 140° F) to -40° C to +70° C (-40° F to 158° F)
- Operating humidity: 0 to 95% RH non-condensing
- Replaces Magnum Energy MS2812-L-U
