C55 T BlueCool 55,000 BTU Chiller, 230 volt | Webasto WBCL1207003D
Special Price
$8,585.85
Regular Price
$13,209.00
SKU
Brand: Webasto
WEBASTO-WBCL1207003D
- Type/Model: C 55T-R-230V-REV-R410a
- BlueCool C Series Twin compressor chiller air conditioning system with Reverse Cycle Heat
- 55,000 BTU/hr Cooling Capacity
- 55,000 BTU/hr Heating Capacity
- 230 volt AC operation
- Frequency 50/60 Hz
- Suggested Breaker 20A(qty 2)
- Rated Current: 17-18A
- Effective value of current consumption (RMS) for the first 40 ms at 60Hz: 56A
- Effective value of current consumption (RMS) for the first 300 ms at 60Hz: 53A
- Max Starting Current at 60Hz: 81A
- Cold Water connections: 1 inch
- Sea Water connections: 1 inch
- Minimum cold water flow rate 10.04 gallons per minute(602.4 GPH) or 38 l/min
- Minimum sea-water flow rate 11.1 gallons per minute(666 GPH) or 42 l/min
- Consider Webasto WB1500 Pump (1,440 GPH), or one offering similar performance, for the cold water loop
- Consider Webasto WB1500/WB2000 (1,440-2,250 GPH), or one offering similar performance, for the sea-water loop
- Max Permissible ambient temperature: 140 degrees Fahrenheit/60 degrees Celsius
- Length of wiring harness from chiller to electrical box: 2 meters (6.56 feet)
- R410A Refrigerant(750 grams x 2)
- Minimum sea water temperature in heating mode: 42.8 degrees Fahrenheit/6 degrees Celsius
- Maximum sea water temperature in cooling mode: 95 degrees Fahrenheit/35 degrees Celsius
- Chiller Unit: 21.65 inch(550mm) Height x 23.23 inch(590mm) Width x 16.14 inch(410mm) Depth
- Electric Box: 12.01 inch(305mm) Height x 19.77 inch(502mm) Width x 5.39 inch(137mm) Depth
- Chiller weight: 189.6 lbs/86 kg
- Installation of a Seawater strainer is mandatory between the seacock and Pump(sold Separately)
- Electric box features a USB diagnosis port enabling qualified tech direct access via the unique BlueCool Expert Tool. Expert tool offers access to stored fault codes by hourly runtime which will allow a qualified technician to accurately and efficiently troubleshoot any problems that may arise.
- Compatible with MyTouch display and display cable(sold separately): WBCL151002C(display) & WBCL151001A(5m cable) or WBCL151005A(10m cable)
- MyTouch control is compatible with the popular Vimar bezels allowing you to maintain a consistent style throughout your yacht(Vimar Eikon, Eikon EVO, Plana, and Bitcino Axolute)
- Optional BlueCool Connect System allows for remote operation and monitoring via the BlueCool Connect application: WEBASTO-2510219B
- This unit is equipped with High Pressure and Low Pressure Service ports
- Replaces Webasto WBCL1207003C
| Manufacturer Part No. | WBCL1207003D |
|---|---|
| Shipping/Dimensional Weight | 218.000000 |
| Actual Weight | 215.32 |
| Brand | Webasto |
| Availability | In Stock |
| Model | BlueCool C |
| Cooling BTU | 55,000 |
| Type | Chiller |
| Ships free when order qualifies | No |
| Hazmat Fee | No |
