Hurth 630 Inline Transmission Gear Diagram
| Ref # | Part # | Description | Qty. |
|---|---|---|---|
| 100 | H451892 | Housing | 1 |
| 101 | ZF-3312301002 | Cover, Housing | 1 |
| 102 | ZF-3312301035 | Vent Cap | 1 |
| 103 | ZF-0630302091 | Spring Washer | 12 |
| 104 | H442375 | Screw Hex | 5 |
| 105 | H452512 | Screw Hex | 1 |
| 106 | H442374 | Screw Hex | 4 |
| 107 | H442376 | Screw Hex | 2 |
| 108 | ZF-3312301030 | Sealing Ring | 1 |
| 109 | H455079 | Screw Hex | 4 |
| 110 | H439223 | Retaining Plate | |
| 111 | H438948 | Suction Pipe | 1 |
| 112 | H438963 | Baffle Plate | 1 |
| 113 | H335817 | Parallel Pin | 2 |
| 114 | ZF-0634319132 | Sealing Ring | 1 |
| 115 | ZF-0630302090 | Spring Washer | 7 |
| 116 | ZF-0636101727 | Screw Socket Head | 7 |
| 117 | ZF-3312108001 | Control Block Assembly | 1 |
| 118 | H455754 | Screw Plug | 1 |
| 119 | H455755 | Washer | 1 |
| 120 | ZF-0636309007 | Screw Plug | 1 |
| 121 | ZF-3312208032 | Shifting Lever | 1 |
| 122 | H455785 | Nut Hex | 1 |
| 123 | VD-1000640004 | Neutral Safety Switch | 1 |
| 124 | ZF-3312308020 | Gasket | 1 |
| 125 | ZF-0636301041 | Screw Plug | 1 |
| 126 | ZF-3312301008 | Washer | 1 |
| 127 | ZF-3312199031 | Fluid Fine Filter | 1 |
| 128 | ZF-3312101003 | Fluid Filter, Complete | 1 |
| 129 | ZF-0634306204 | O-Ring | 1 |
| 130 | ZF-0634304688 | O-Ring | 1 |
| 131 | N/A | Dipstick | 1 |
