- Surge Guard Model 41390-RVC provides premium protection for your motor home and enhanced features over other transfer switches on the market
- Total electrical protection for your RV
- Protects your RV bumper to bumper from faulty park power
- Optional easy to read LCD display constantly monitors and displays the condition of power being supplied to your RV
- RVC communication allows instant display of voltage, current and fault conditions on an RVC compatible device
- Automatic Transfer Switch Features
- Transfers to generator power automatically when energized after 30 second delay
- When both shore power and generator power are available, generator dominates after a 30 second delay
- Once the generator is shut down, shore power activates after a 3-4 second delay
- 90A full rated contactor mounted on vibration isolators to ensure quiet operation
- Over/under voltage protection
- Contactor opens outside of 95V and 132V range after 9-second delay
- Instantaneous trip at voltages above 140V and below 70V
- Over/under frequency protection
- Contactor opens outside of (54-70Hz) range after 30-second delay
- Source power connection integrity
- Contactor will not close or will open in the event of an open source conductor or miswired. L1, L2, Neutral and Ground
- Brown/blackout protection 2 min 15 second delay is initiated after removal of power to ensure AC compressor head bleed off, feature can be disabled on remote. (optional)
- Measures and displays both L1 & L2 load current independently
- 4-mode protection, 3,350 Joules
- Energy capacity - 130,000 Amps peak
- Fuse protected L1/L2 surge suppressors
- Plain text display (Replace Surge) of open fuses indicating a failed MOV or open surge connection
- Remote Panel Indicator (Optional) 40272
- Continuous visual indication of source voltage (L1, L2) load current or diagnostics
- Plain English display of faults. No cryptic error codes
- LCD technology with automatic light-sensitive backlighting for easy reading in any ambient light condition
- 3rd Party Display Systems
- RS232 proprietary output data stream for communication with external equipment
| Manufacturer Part No. | 41390RVC |
|---|---|
| Brand | Southwire |
| Shipping/Dimensional Weight | 33.000000 |
| Actual Weight | 33 |
| Availability | Out of Stock |
| Ships free when order qualifies | Yes |
| Hazmat Fee | No |
