Velvet Drive 72C 1.523:1 Reduction Unit Diagram (Early Style)
| Ref # | Part # | Description | Qty. |
|---|---|---|---|
| 1 | VD-4775L | Coupling Nut | 1 |
| 2 | VD-4547AY | Coupling (72C Only) | 1 |
| 2B | ALTO-023323 | Coupling (71C Only) | 1 |
| 3 | VD-179860 | Hex head bolt (7/16-14 x 1 1/4) | 6 |
| 4 | VD-103322 | Lockwasher (7/16) | 6 |
| 5 | VD-L4-7 | Bearing retainer | 1 |
| 6 | VD-L4-147 | Bearing retainer gasket | 1 |
| 7 | VD-71C-110 | Oil seal | 1 |
| 8 | N/A | Bearing, no longer supplied | 1 |
| 9 | N/A | Main shaft, no longer supplied | 1 |
| 10 | N/A | Sun gear, no longer supplied | 1 |
| 11 | VD-4808 | Spring pin | 1 |
| 12 | N/A | Pinion cage drive pin, no longer supplied | 1 |
| 13 | N/A | Expansion plug, no longer supplied | 1 |
| 14 | N/A | Reduction housing, no longer supplied | 1 |
NOTE: These EARLY production parts are not interchangeable with CURRENT production parts. All other parts are the same.
