Velvet Drive 72C 2.57:1 & 2.91:1 Reduction Unit Diagram (Early Style)
| Ref # | Part # | Description | Qty. |
|---|---|---|---|
| 1 | ALTO-023320 | Coupling nut | 1 |
| 2 | VD-4912 | Coupling (72C Only) | 1 |
| 3 | VD-179860 | Hex head bolt (7/16-14 x 1 1/4) | 6 |
| 4 | VD-103322 | Lockwasher (7/16) | 6 |
| 5 | VD-L4-7 | Bearing retainer | 1 |
| 6 | VD-L4-147 | Bearing retainer gasket | 1 |
| 7 | VD-71C-110 | Oil seal | 1 |
| 8 | VD-4920 | Bearing | 1 |
| 9 | VD-L6-A2D | Pinion cage and output shaft assembly (2.57:1 only) | 1 |
| 9A | VD-L7-A2D | Pinion cage and output shaft assembly (2.91:1 only) | 1 |
| 10 | VD-L7-1A | Reduction housing, no longer supplied | 1 |
NOTE: These EARLY production parts are not interchangeable with CURRENT production parts. All other parts are the same.
