ZF 63A Inline Transmission Control Block Assembly Diagram
| Ref # | Part # | Description | Qty. |
|---|---|---|---|
| 1 | ZF-3312199004 | Electric selector valve - 12v | 1 |
| ZF-3312199005 | Electric selector valve - 24v | 1 | |
| 2 | • Control valve | 1 | |
| 3 | ZF-3312308020 | Gasket | 1 |
| 4 | ZF-3312308064 | Electric valve - 12v | 2 |
| ZF-3312308065 | Electric valve - 24v | 2 | |
| 5 | ZF-0634304651 | O-ring | 2 |
| 6 | ZF-0634304391 | Piston ring | 2 |
| 7 | ZF-0630502078 | Snap ring | 2 |
| 8 | ZF-3312308054 | Valve piston | 2 |
| 9 | ZF-3312308062 | Piston spring | 2 |
| 10 | ZF-0636302053 | Plug | 4 |
| 11 | ZF-3312308059 | Drilled plug | 2 |
| 12 | ZF-0634801302 | Washer | 4 |
| 13 | ZF-0636101651 | Screw | 2 |
| 14 | ZF-0630001096 | Washer | 2 |
| 15 | ZF-1043326045 | Valve lock | 2 |
| 16 | ZF-3312308063 | Plug | 1 |
| 17 | ZF-0634306524 | O-ring | 1 |
| 18 | ZF-0636101727 | Hex head screw | 6 |
| 19 | ZF-0630302090 | Washer | 6 |
| 20 | ZF-0630532004 | Snap ring | 1 |
| 21 | ZF-0634304309 | O-ring | 1 |
| 22 | ZF-3312308058 | Plug | 1 |
| 23 | ZF-3312308040 | Spring | 1 |
| 24 | ZF-3312308043 | Spring guide pin | 1 |
| 25 | ZF-3312308046 | Valve piston | 1 |
| 26 | ZF-3312302041 | Piston ring | 3 |
| 27 | ZF-3312117001 | Connectors kit | 1 |
| 28 | ZF-0631501062 | Key | 1 |
| 29 | ZF-978.28.641.01 | Seal | 1 |
