ZF 63A Inline Transmission Housing Diagram
| Ref # | Part # | Description | Qty. |
|---|---|---|---|
| 1 | ZF-3312301004 | Housing | 1 |
| 2 | ZF-0636304041 | Plug | 1 |
| 3 | ZF-0634319132 | Output shaft seal | 1 |
| 4 | ZF-3312101003 | Filter cover assembly | 1 |
| 5 | • Filter cover | 1 | |
| 6 | ZF-0634304688 | • O-ring | 1 |
| 7 | ZF-0634306204 | O-ring | 1 |
| 8 | ZF-3312301007 | Oil filter | 1 |
| 9 | ZF-3312301008 | Sealing washer | 1 |
| 10 | ZF-3312199031 | Oil filter assembly | 1 |
| 11 | ZF-0634304688 | • O-ring | 1 |
| 12 | ZF-0634306204 | O-ring | 1 |
| 13 | ZF-3312301007 | • Oil filter | 1 |
| 14 | ZF-3312301005 | Suction pipe | 1 |
| ZF-3312301033 | Suction pipe with support | 1 | |
| 15 | ZF-3312301013 | Retaining plate | 1 |
| 16 | ZF-0636113006 | Hex head screw (for 3312301005) | 2 |
| ZF-0636115020 | Hex head screw (for 3312301033) | 2 | |
| 17 | ZF-0631315520 | Locator pin | 2 |
| 18 | ZF-3312301002 | Cover (housing) | 1 |
| ZF-3312301003 | Cover (housing) | 1 | |
| 19 | ZF-978.36.701.02 | Oil dipstick | 1 |
| ZF-3312201002 | Oil dipstick | 1 | |
| 20 | ZF-0634304405 | • O-ring | 1 |
| 21 | ZF-3312301035 | Breather valve | 1 |
| 22 | ZF-3312301030 | Input shaft seal | 1 |
| 23 | ZF-0630302091 | Washer | 12 |
| 24 | ZF-0636010550 | Hex head screw | 4 |
| 25 | ZF-0636015227 | Hex head screw | 5 |
| 26 | ZF-0636010572 | Hex head screw | 2 |
| 27 | ZF-0636015386 | Hex head screw | 1 |
| 28 | ZF-0636113006 | Hex head screw | 1 |
| ZF-0636015020 | Hex head screw | 1 | |
| 29 | ZF-0630001046 | Washer | 1 |
| 30 | ZF-3312301011 | Buffle plate | 1 |
| ZF-3312301012 | Buffle plate | 1 | |
| 31 | ZF-0636113006 | Hex head screw | 2 |
| ZF-0636015020 | Hex head screw | 2 | |
| 32 | ZF-0630001046 | Washer | 2 |
| 33 | ZF-3312301006 | Buffle plate | 1 |
